Capped Low-Profile Turrets
1 Inch Split-tube chassis
Multi-Coated lenses
High torque zoom ring
Fast focus eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
Parallax: Adjustable Objective
9-11mm mounts included.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
The classic Mil Dot features multiple aim points for hold-over and hold-under. Accurate mil spacing on 10x, featuring 4 Mil Dots in each direction. Glass etched reticle that has 5 brightness levels of illumination in both red and green, or can be turned off for a solid black reticle.
Technical Specifications:
Length: 351mm
Weight: 595g
Eye relief: 89mm
Focus/Parallax – AO : 9m – Infinity
Field of View: 11.2-3.6m @100m
Exit Pupil: 17-6mm
Chassis: 1″ Split-tube
Optical System: 3-9×
Objective: 50mm
Illumination: Red/Green
Reticle: Mil Dot
Elevation Increment: 1⁄4 MOA
Elevation Adjustment Range: 90 MOA
Windage Increment: 1⁄4 MOA
Windage Adjustment Range: 90 MOA
Material: Aluminium
Ocular Type: Fast Focus
Lens Coating: Multi-Coated
Power Selector Style: Knurled Posi-Grip
Focal Plane: Second Focal Plane (SFP)
Turret Caps: Yes
Turret Type: Low Profile
